Chat

The Chat feature allows players to communicate together in-game with text chat.

The purpose of this feature is to allow players to communicate together in-game with text chat.

Here are some common use cases for the Chat feature:

• Single Player Games: Broaden the metagame with social features to boost retention
• Multiplayer Games: Deepen the core game to increase engagement. See Multiplayer for more info

Here is the main chat-related terms to be aware.

Name	Detail
Room	A collection of game players (e.g. chatting about a specific topic)
Room Player	A game player within the room
Message	Text sent from one player to all players within the room

Chat API

Experimental API

This API is experimental and may change in future versions.

Unlike many Beamable Features, Chat does not require a specific Beamable Feature Prefab to be used. The main entry point to this feature is C# programming.

Players can easily send and receive messages in real-time.

The main API highlights include ChatService.

Method Name	Detail
Subscribe	Callback to observe changes
CreateRoom	Create a new room
GetMyRooms	Get list of all current rooms
LeaveRoom	Leave the current room
SendMessage	Send a text message to all room players

Sending Room Message

room.SendMessage("Hello World!");

Receiving Room Message

private void OnMessageReceived (Message message)
{
  Debug.Log($"Message = {message.content}");
}

Group Chat

Players can create groups, interact, and chat with group members in real-time. See Groups for more info.

Filtering Chat Messages

Beamable supports filtering chat messages to help keep the game chat safe.

public async void IsProfanity()
{
    string text = "pornography"; // Ex. This string is profane

    bool isProfanityText = true;
    try
    {
        var result = await _beamContext.Api.Experimental.ChatService.ProfanityAssert(text);
        isProfanityText = false;
    } catch{}

    Debug.Log($"isProfanityText = {isProfanityText} for {text}");
}

Limitations

It's worth noting that chat rooms have no specified limit to their capacity. While the network may be perfectly capable of processing messages from hundreds of users, the game clients will start flooding with messages before it becomes a performance problem.

Code Samples

In this example, the player may create a room and send a chat message.

ChatServiceExample.cs

using System.Collections.Generic;
using System.Threading.Tasks;
using Beamable.Common.Api;
using UnityEngine;
using Beamable.Experimental.Api.Chat;
using UnityEngine.Events;

namespace Beamable.Examples.Labs.ChatService
{
    /// <summary>
    /// Holds data for use in the <see cref="ChatServiceExampleUI"/>.
    /// </summary>
    [System.Serializable]
    public class ChatServiceExampleData
    {
        public List<string> RoomNames = new List<string>();
        public List<string> RoomPlayers = new List<string>();
        public List<string> RoomMessages = new List<string>();
        public string RoomToCreateName = "";
        public string RoomToLeaveName = "";
        public bool IsInRoom = false;
        public string MessageToSend = "";
    }

    [System.Serializable]
    public class RefreshedUnityEvent : UnityEvent<ChatServiceExampleData> { }

    /// <summary>
    /// Demonstrates <see cref="ChatService"/>.
    /// </summary>
    public class ChatServiceExample : MonoBehaviour
    {
        //  Events  ---------------------------------------
        [HideInInspector]
        public RefreshedUnityEvent OnRefreshed = new RefreshedUnityEvent();

        //  Fields  ---------------------------------------
        private ChatView _chatView = null;
        private BeamContext _beamContext;
        private ChatServiceExampleData _data = new ChatServiceExampleData();

        //  Unity Methods  --------------------------------
        protected void Start()
        {
            Debug.Log("Start()");

            SetupBeamable();
        }

        //  Methods  --------------------------------------
        private async void SetupBeamable()
        {
            _beamContext = BeamContext.Default;
            await _beamContext.OnReady;

            Debug.Log($"beamContext.UserId = {_beamContext.UserId}");

            // Observe ChatService Changes
            _beamContext.Api.Experimental.ChatService.Subscribe(chatView =>
            {
                _chatView = chatView;

                // Clear data when ChatService changes
                _data.RoomNames.Clear();
                _data.RoomMessages.Clear();
                _data.RoomPlayers.Clear();

                foreach(RoomHandle room in chatView.roomHandles)
                {
                    room.OnRemoved += Room_OnRemoved;

                    string roomName = $"{room.Name}";
                    _data.RoomNames.Add(roomName);

                    room.Subscribe().Then(_ =>
                    {
                        // Clear data (again) when Room changes
                        _data.RoomMessages.Clear();
                        _data.RoomPlayers.Clear();
                        _data.RoomToLeaveName = room.Name;

                        foreach(var message in room.Messages)
                        {
                            string roomMessage = $"{message.gamerTag}: {message.content}";
                            _data.RoomMessages.Add(roomMessage);
                        }


                        foreach(var player in room.Players)
                        {
                            string playerName = $"{player}";
                            _data.RoomPlayers.Add(playerName);
                        }

                        Refresh();
                    });
                    room.OnMessageReceived += Room_OnMessageReceived;
                }
                Refresh();
            });
        }



        public async Task<bool> IsProfanity(string text)
        {
            bool isProfanityText = true;
            try
            {
                var result = await _beamContext.Api.Experimental.ChatService.ProfanityAssert(text);
                isProfanityText = false;
            } catch{}

            return isProfanityText;
        }

        public async Task<EmptyResponse> SendRoomMessage()
        {
            string messageToSend = _data.MessageToSend;

            bool isProfanity  = await IsProfanity(messageToSend);

            if (isProfanity)
            {
                // Disallow (or prompt Player to resubmit)
                messageToSend = "Message Not Allowed";
            }

            foreach(RoomHandle room in _chatView.roomHandles)
            {
                if (room.Players.Count > 0)
                {
                    await room.SendMessage(messageToSend);
                }
            }

            return new EmptyResponse();
        }

        public async Task<EmptyResponse> CreateRoom ()
        {
            string roomName = _data.RoomToCreateName;
            bool keepSubscribed = false;
            List<long> players = new List<long>{_beamContext.PlayerId};

            var result = await _beamContext.Api.Experimental.ChatService.CreateRoom(
                roomName, keepSubscribed, players);

            Refresh();

            return new EmptyResponse();
        }

        public async Task<EmptyResponse> LeaveRoom()
        {
            var roomInfos = await _beamContext.Api.Experimental.ChatService.GetMyRooms();

            foreach(var roomInfo in roomInfos)
            {
                var result = await _beamContext.Api.Experimental.ChatService.LeaveRoom(roomInfo.id);
            }

            Refresh();

            return new EmptyResponse();
        }

        public void Refresh()
        {
            _data.IsInRoom = _data.RoomPlayers.Count > 0;

            // Create new mock message
            int messageIndex = _data.RoomMessages.Count;
            _data.MessageToSend = $"Hello {messageIndex:000}!";

            // Create new mock group name
            int groupIndex = _data.RoomNames.Count;
            _data.RoomToCreateName = $"Room{groupIndex:000}";

            // Create temp name for pretty UI
            if (string.IsNullOrEmpty(_data.RoomToLeaveName))
            {
                _data.RoomToLeaveName = _data.RoomToCreateName;
            }

            // Log
            string refreshLog = $"Refresh() ...\n" +
                                $"\n * RoomNames.Count = {_data.RoomNames.Count}" +
                                $"\n * RoomPlayers.Count = {_data.RoomPlayers.Count}" +
                                $"\n * RoomMessages.Count = {_data.RoomMessages.Count}" +
                                $"\n * IsInRoom = {_data.IsInRoom}\n\n";

            Debug.Log(refreshLog);

            // Send relevant data to the UI for rendering
            OnRefreshed?.Invoke(_data);
        }

        //  Event Handlers  -------------------------------
        private void Room_OnMessageReceived(Message message)
        {
            string roomMessage = $"{message.gamerTag}: {message.content}";
            Debug.Log($"Room_OnMessageReceived() roomMessage = {roomMessage}");
            _data.RoomMessages.Add(roomMessage);
            Refresh();
        }

        private void Room_OnRemoved()
        {
            Debug.Log($"Room_OnRemoved");
            Refresh();
        }
    }
}
